We are specialized in offering precision engineered ASTM A213 T5 Alloy Steel Seamless Tube, which are used in various engineering applications. These tube are used in various application industry like Petroleum,chemical,power, gas, water, metallurgy, shipbuilding, construction etc. These products are presented in different shape and sizes, grades they are applicable both for engineering and industrial purpose. We are Offered at competitive prices, these are developed using advanced technology.
| Size (Seamless) | : | 6.35mm o.d to 101.60mm o.d |
| Standards | : | ASTM A213, ASME SA213 |
| Equivalent Standards | : | EN 10216-2, ASTM A335, GOST 550-75 |
| Material | : | P5, K41545 |
| Equivalent Material | : | T5, 15Ch5M |
| Type | : | Seamless |
| Specialized in | : | Large Diameter Size |
| Outer Dimensions | : | 6-2500mm; WT:1-200mm |
| Wall Thickness | : | Schedule 3mm to 15mm. |
| Length | : | max 1~12m |
| Schedule | : | STD, SCH40, SCH80 |
| Form | : | Round, Square, Rectangular, Hydraulic Etc. |
| Length | : | Single Random, Double Random & Cut Length. |
| Tubing End | : | Plain End, Beveled End, Treaded. |
| C, % | Mn, % | P, % | S, % | Si, % | Cr, % | Mo, % |
| 0.15 max | 0.30-0.60 | 0.025 max | 0.025 max | 0.50 max | 4.00-6.00 | 0.45-0.65 |
| Tensile Strength , MPa | Yield Strength, MPa | Elongation, % | Hardness, HB |
| 415 min | 205 min | 30 min | 163 max |
| Hot rolled | Outside Diameter, mm | Tolerance, mm |
| OD≤101.6 | +0.4/-0.8 | |
| 101.6＜OD≤190.5 | +0.4/-1.2 | |
| 190.5＜OD≤228.6 | +0.4/-1.6 | |
| Cold Drawn | Outside Diameter, mm | Tolerance, mm |
| OD＜25.4 | ±0.10 | |
| 25.4≤OD≤38.1 | ±0.15 | |
| 38.1＜OD＜50.8 | ±0.20 | |
| 50.8≤OD＜63.5 | ±0.25 | |
| 63.5≤OD＜76.2 | ±0.30 | |
| 76.2≤OD≤101.6 | ±0.38 | |
| 101.6＜OD≤190.5 | +0.38/-0.64 | |
| 190.5＜OD≤228.6 | +0.38/-1.14 |
| Hot rolled | Outside Diameter, mm | Tolerance, % |
| OD≤101.6, WT≤2.4 | +40/-0 | |
| OD≤101.6, 2.4＜WT≤3.8 | +35/-0 | |
| OD≤101.6, 3.8＜WT≤4.6 | +33/-0 | |
| OD≤101.6, WT>4.6 | +28/-0 | |
| OD>101.6, 2.4＜WT≤3.8 | +35/-0 | |
| OD>101.6, 3.8＜WT≤4.6 | +33/-0 | |
| OD>101.6, WT>4.6 | +28/-0 | |
| Cold Drawn | Outside Diameter, mm | Tolerance, % |
| OD≤38.1 | +20/-0 | |
| OD>38.1 | +22/-0 |
Length: 5800mm; 6000mm; 6096mm; 7315mm; 11800mm; 12000mm; and so on.
Max length: 16000mm, also U bending can be offered.
