Sumico Metal was the first company in India who was awarded the order to Supply Stainless Steel Threaded Fittings & Flanges by Indian Oil Corporation for their refinery at Mundra. In 2008 Jordan Petroleum Refinery Company Limited selected Sumico Metal to supply stainless steel butt weld fittings & alloy steel Threaded Fittings to Amman, Jordan out of 6 top manufacturers of Threaded Fittings in INDIA based on pressure rating of our Threaded Fittings.
Sumico Metal (I) Pvt. Ltd. is an approved manufacturer of high nickel based special alloy buttweld pipe fittings and stainless steel Threaded Fittings, ss socket weld fittings, stainless pipe fittings, seam welded 100% radiography tested pipe fittings to requirements of BVIS, IBR, BARC, DNV, BHEL & we are ISO 9001:2008, 14001:2004, OHSAS 18001:2007 certified company.
Contents:
Threaded Fittings Material, Size & Specification
| Specification |
|
|---|---|
| Threaded pipe fittings Dimension | ANSI B 16.11 |
| Threaded pipe fittings Size | 1/4" NB TO 4" NB |
| Thread fitting Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Threaded fittings Range | Coupling, Plug, Socket, Bushing, Elbow, Tee, Nipple, Union,Threading Outlet, Welding Outlet, Sockt Weld Outlet. |
| Stainless Steel Threaded Fittings | ASTM A182 F304, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L |
| Duplex Steel Threaded fittings | ASTM A 182 –F51 / F52 / F53 / F54 / F55 / F57 / F59 / F60 / F61 S 31803, S 32205, S 32550, S 32750, S 32760 |
| Carbon Steel Threaded fittings | ASTM/ ASME A 105, ASTM/ ASME A 350 LF 2 |
| Alloy Steel Threaded fittings | ASTM / ASME A 182 GR F5, F 9, F 11, F 12, F 22, F 91. |
| Copper Alloys Threaded fittings | ASTM / ASME SB 111 UNS NO. C 10100 , C 10200 , C 10300 , C 10800 , C 12000, C 12200, C 70600 C 71500 ASTM / ASME SB 466 UNS NO. C 70600 (CU -NI- 90/10) , C 71500 (CU -NI- 70/30) |
| Nickel Alloy Threaded fittings | ASTM / ASME SB 336, ASTM / ASME SB 564 / 160 / 163 / 472, UNS 2200 (NICKEL 200) , UNS 2201 (NICKEL 201), UNS 4400 (MONEL 400), UNS 8020 (ALLOY 20 / 20 CB 3), UNS 8825 INCONEL (825) , UNS 6600 (INCONEL 600), UNS 6601 (INCONEL 601) , UNS 6625 (INCONEL 625) , UNS 10276 (HASTELLOY C 276) |
Threaded Fittings Project Reference List
Sumico Metal supplied Forged Pipe Fittings in more then 37 countries in last 10 years
| PROJECT NAME / CUSTOMER | Sumico Metal SUPPLIED | GRADES | LOCATION | YEAR |
|---|---|---|---|---|
| INDORAMA | Threaded Fittings AND BRANCH OUTLETS BW – SW – THRD | A105 – A350 LF2 – A106B- A333 GR6 – A234 WPB – A420 WPL6 – A182 F304L | THE NETHERLANDS | 2015 |
| GAS AND CONDENSATE EXPORT SYSTEM | Threaded Fittings AND BRANCH OUTLETS BW – SW | A182 F316L – A182F44 A182 F44 , A312S31254, A182 F316L, A105.N, A105 HDG, A350 LF2, A106 Gr.B, A106 Gr.B HDG , A333 Gr.6, A234 WPB |
KUWAIT | 2015 |
| GAS DEVELOPMENT PROJECT | Threaded Fittings, BRANCH OUTLETS | INCOLOY 825 | INDONESIA | 2015 |
| QUALITY STAMP TRADING -SAUDI ARAMCO | Threaded Fittings , BRANCH OUTLETS SW | A105, A105 GALV, A350 LF2, A182F304L, A182F316L, A403 WP316L, A182F321, A182F44, A182F5, CU90/10 UNS C70610 |
SAUDI ARABIA | 2014-2015 |
| REFINERY OFF GAS PROJECT | Threaded Fittings, BRANCH OUTLETS BW-THRD, NIP OUTLETS | A105, A105 HDG A350 LF2, A182 F304/ 304L, A182F316/316L, A182F11, A105N, A106B, A234WPB, A333 |
BELGIUM | 2014-2015 |
| MA’ADEN WA’AD AL SHAMAL PHOSPHATE | Threaded Fittings AND BRANCH OUTLETS SW-BW | A350LF2, F304L, F316L, F904L, A182F60, ALLOY20 A105N, A106B, A234WPB, |
SAUDI ARABIA | 2014-2015 |
| NORTH WEST REDWATER | Threaded Fittings SW & NPT | A350LF2,A420WPL6, A182F304L-F316L,WP304L,HAST,C276 |
CANADA | 2014-2015 |
| CANADA NWR PROJECT | Threaded Fittings , BRANCH OUTLETS SW & NPT | F304L/316L/317L/347H/321H F11/F22/ UNS08825 |
CANADA | 2014-2015 |
| DENIZ 2 PROJECT | Threaded Fittings SW & NPT | A 105, A105 GALVA, A350LF2, A333 Gr6, A234WPB-A420WPL6, F304L, WP304L |
AZERBAIJAN | 2014 |
| ADMA OPCO ABU DHABI | Threaded Fittings, BRANCH OUTLETS BW-THRD, LATERAL, OUTLETS | A694 F52, A182F321, A182F316, A105.N, A312TP316L, A312 TP321, A182 F53 SUPER DUPLEX |
UAE | 2014 |
| SAUDI ARAMCO HOLLAND | Threaded Fittings | CuNi 9010 | SAUDI ARABIA | 2014 |
| MISSAN OIL Comp.PETROCHINA IRAQ | API COUPLINGS | L80 | IRAQ | 2014 |
| SAUDI ARAMCO | Threaded Fittings, BRANCH OUTLETS BW-SW-THRD | MONEL 400, A182 F5, A182F316L, A182F304L, A105 |
SAUDI ARABIA | 2014 |
| OIL AND GAS INC | Threaded Fittings AND BRANCH OUTLETS BW | UNS NO 6625 | BRAZIL | 2014 |
| SHIDDIRGANG PROJECT | Threaded Fittings, BRANCH OUTLETS BW-SW-THRD | BANGLADESH | 2014 | |
| SAUDI ARABIAN MINING COMPANY | Threaded Fittings AND BRANCH OUTLETS SW – BW | A105, A105 GALV, A350LF2A182F304L, A182F316L |
SAUDI ARABIA | 2014 |
| GAS TURBINE POWER PLANT PROJECT | Threaded Fittings AND BRANCH OUTLETS SW | A105, A182F316L | IRAQ | 2014 |
| GRUPO CUNADO | FORGED STEEL FITTINGS | A105,A182F304L, A182F316L,F321, | TURKEY | 2013-2014 |
| ALSTOM | FORGED STEEL FITTINGS AND BRANCH OUTLETS | A105, A182F304L, A182F316L | MOROCCO, SOUTH AFRICA |
2010 |
 |
.jpg) |
.jpg) |
.jpg) |
Stainless Steel Forged Fittings |
Alloy Steel Forged Fittings |
Carbon Steel Forged Fittings |
Duplex Steel Forged Fittings |
Equivalent Quality & Price with below Manufacturers of Forged Fittings
Raccortubi S.p.A. Forged Fittings, Italy |
Erne Fittings Forged Fittings, Austria |
Melesi Forged Fittings, Italy |
Mega Forged Fittings, Italy |
Ulma Forged Fittings, Spain |
TecnoForge Forged Fittings, Italy |
BENKAN Corporation Forged Fittings, Japan |
BKL- Thai Benkan Forged Fittings, Thailand |
Lame S.r.l. Forged Fittings, Italy |
Metal far Forged Fittings, Italy |
Threaded Fittings Dimensions
|
|
90º Elbow: 2,000 PSI Weights (LBS) • Dimensions (IN) • QTY (Case Quantity)
| SIZE | A | B | QTY | WEIGHT |
|---|---|---|---|---|
¼ |
0.81 |
0.88 |
160 |
0.20 |
⁄ |
0.97 |
1.00 |
130 |
0.26 |
½ |
1.12 |
1.31 |
100 |
0.57 |
¾ |
1.31 |
1.5 |
75 |
0.71 |
1 |
1.5 |
1.81 |
40 |
1.08 |
1 ¼ |
1.75 |
2.19 |
25 |
1.68 |
1 ½ |
2.00 |
2.44 |
18 |
2.38 |
2 |
2.38 |
2.97 |
10 |
3.55 |
2 ½ |
3.00 |
3.62 |
4 |
6.22 |
3 |
3.38 |
4.31 |
2 |
10.36 |
4 |
4.19 |
5.75 |
1 |
23.91 |
