Hardox 500 (Abrex 500)

Hardox 500 Plates, Abrex 500 Plate, Hardox 500 Sheets, Abrex 500 Sheets Manufacturer, Exporter & Suppliers.

Abrasion Resistant Steel Plates, Hardox 500 Sheets & Plates, Abrex 500 Plates Suppliers in India.

We are engaged Stockiest, Manufacturers, Suppliers & Exporter of wide range of Hardox 500 ( Abrex 500 ) in Mumbai, India. These HARDOX 500 Plates is an abrasion resistant plate with a hardness of 500 HBW, intended for applications where demands are imposed on abrasion resistance in combination with good cold bending properties. These are available in verious specification & thickness as per the requirements of clients. These are easily available at economical price range in the market. These steel plates are the widely used of the wear resistant grades. We make all the sizes and thickness of Hardox 500 Plates as per the clients requirements.

Specification :

Size	:	5mm ~ 120 mm
Width	:	1450mm to 4050mm.
Length	:	3000mm to 15000mm
Thickness	:	3mm to 130mm
Applications	:	Cutting Edges, Grizzly bars, Buffer bins, Measuring bins and Skips

Chemical Composition :

Plate	C	Si	Mn	P	S	Cr	Ni	Mo	B	CEV	CET
thickness mm	max %	max %	max %	max %	max %	max %	max %	max %	max %	typv	typv
04/13/13	0.27	0.7	1.6	0.025	0.01	1	0.25	0.25	0.004	0.49	0.34
(13)-32	0.29	0.7	1.6	0.025	0.01	1	0.5	0.3	0.004	0.62	0.41
(32)-40	0.29	0.7	1.6	0.025	0.01	1	1	0.6	0.004	0.64	0.43
(40)-80	0.3	0.7	1.6	0.025	0.01	1.5	1.5	0.6	0.004	0.74

Mechanical Property :

Grade	Mechanical Property			Charpy V Impact Test
HADOX 500	HBW Thickness/Mpa		Elongation	Degree	longitudinal
	4-32MM	470-530	Min %	-40	J
	(32)-80	450-540	10	-40	40
