Sumico Metal is one of the leading Manufacturers, Supplier and Exporters of high quality ANSI / ASME / ASA B16.5 Flanges in mumbai, india. We offer a wide range of Flanges as per various ASME, DIN, BS, AWWA Standards or as per customer's drawing. They are conforming to national & international standards and they are hubless. These Flanges is available in various size, grades, Specification & thickness as per the clients requirments. These Flanges are used in various applications industry.
| Size | : | 1/2" (DN15) ~ 60" (DN1500) |
| Class | : | 150#, 300#, 400#, 600#, 900#, 1500#, 2500# |
| Dimension | : | ANSI/ASME B16.36, ANSI/ASME B16.48 (API 590), ANSI/ASME B16.47 Series A (MSS SP-44), ANSI/ASME B16.47 Series B (API 605), ANSI/ASME B16.5 |
| Type | : | Welding Neck Flange, WN Flange (Raised Face) |
| Face Type Flanges | : | Ring Joint (RJT), Flat Face (FF), Raise Face (RF) |
| Type of Blind Flanges | : | Slip On Flanges, Weld Neck Flanges, Blind Flanges |
| DIN Plate Flanges (Slip On Flanges) | DIN Weld Neck Flanges | DIN Blind Flanges |
| ASME / ANSI B16.5 Flange 150 Class | ASME / ANSI B16.5 Flange 150 Class | ASME / ANSI B16.5 Flange 150 Class |
| ASME / ANSI B16.5 Flange 300 Class | ASME / ANSI B16.5 Flange 300 Class | ASME / ANSI B16.5 Flange 300 Class |
| ASME / ANSI B16.5 Flange 600 Class | ASME / ANSI B16.5 Flange 600 Class | ASME / ANSI B16.5 Flange 600 Class |
| ASME / ANSI B16.5 Flange 900 Class | ||
| ASME / ANSI B16.5 Flange 1500 Class | ||
| ASME / ANSI B16.5 Flange 2500 Class |
| ANSI/ASME/ASA B16.5 300lb/sq.in. Flange BLIND-RF | |||||||
ø |
D |
b |
g |
k |
Holes |
l |
Kg. |
1/2" |
95,2 |
14,3 |
34,9 |
66,7 |
4 |
15,9 |
0,700 |
3/4" |
117,5 |
15,9 |
42,9 |
82,5 |
4 |
19,0 |
1,200 |
1" |
123,8 |
17,5 |
50,8 |
88,9 |
4 |
19,0 |
1,500 |
1 1/4" |
133,3 |
19,0 |
63,5 |
98,4 |
4 |
19,0 |
2,000 |
1 1/2" |
155,6 |
20,6 |
73,0 |
114,3 |
4 |
22,2 |
2,900 |
2" |
165,1 |
22,2 |
92,1 |
127,0 |
8 |
19,0 |
3,400 |
2 1/2" |
190,5 |
25,4 |
104,8 |
149,2 |
8 |
22,2 |
5,100 |
3" |
209,5 |
28,6 |
127,0 |
168,3 |
8 |
22,2 |
7,000 |
3 1/2" |
228,6 |
30,2 |
139,7 |
184,1 |
8 |
22,2 |
8,900 |
4" |
254,0 |
31,7 |
157,2 |
200,0 |
8 |
22,2 |
11,800 |
5" |
279,4 |
34,9 |
185,7 |
234,9 |
8 |
22,2 |
15,500 |
6" |
317,5 |
36,5 |
215,9 |
269,9 |
12 |
22,2 |
21,300 |
8" |
381,0 |
41,3 |
269,9 |
330,2 |
12 |
25,4 |
35,200 |
10" |
444,5 |
47,6 |
323,8 |
387,3 |
16 |
28,6 |
57,000 |
12" |
520,7 |
50,8 |
381,0 |
450,8 |
16 |
31,7 |
82,000 |
14" |
584,2 |
54,0 |
412,7 |
514,3 |
20 |
31,7 |
106,000 |
16" |
647,7 |
57,1 |
469,9 |
571,5 |
20 |
34,9 |
140,000 |
18" |
711,2 |
60,3 |
533,4 |
628,6 |
24 |
34,9 |
178,000 |
20" |
774,7 |
63,5 |
584,2 |
685,8 |
24 |
34,9 |
223,000 |
22" |
838,2 |
66,7 |
641,2 |
742,9 |
24 |
41,3 |
270,000 |
24" |
914,4 |
69,8 |
692,1 |
812,8 |
24 |
41,3 |
345,000 |
